TrailMaster C50 150cc Gas Dirt Bike, 4-Speed Manual Clutch (17/14) Wheels – Red

The TM C50 is a great mid-size dirt bike. It has a high performance 145cc 4 stroke 9.1hp engine with electric & kick start and a top speed of around 55 MPH and a seat height of 33.5”. It is available in red, green, and orange colors. The TM C50 features a 4-speed manual transmission with front and rear disc brakes and inverted front shocks! This is sure to be a HOT seller!
The bikes full on motocross ergonomics and race suspension system make handling feel natural and unforced, and help it navigate over almost any type of terrain. Electronic CDI ignition makes kick starting effortless, keeps the bike running smoothly in all gears and provides a broad, even power band. And at only 172 pounds, the 145cc engine can propel the motorcycle to speeds of 55 miles per hour.
Features:
Powerful 150cc 4-stroke oil cooled engine
Kick start
4-speed, manual clutch
49.8“ wheelbase and 33.5” seat high
Front tire 17”/Rear Tire 14”
Hydraulic front and rear disc brakes
Aluminum handlebar
LED Headlight
Foldable Clutch & Brake Lever
Specifications
Engine System
Engine Type ZM-Single Cylinder, 4-Stroke, Oil Cooling
Displacement 145 ml
Max Power 6.8 /8500（1±5%） kw/r/min
Max Torque 11 /5500（1±5%） N.m/r/min
Compression Ratio 9.0:1
Bore and Stroke 56.5 x 57.8 (mm×mm)
Shift Type N-1-2-3-4, Four-Gear Manual Shift
Start Type Kick Start
Ignition CDI
Min. Fuel Consumption: ≤367g/kw.h
Engine Oil #： SJ-5W/40
Transmission Chain Drive; #428 & 110L Chain，14/41T
Size Data
Overall Size (L x W x H) 71.3″*28.9″*43.3″(1810*735*1100MM)
Wheelbase 49.8″ (1265MM)
Seat Height 33.5″ (850MM)
Ground Clearance 13″ (330MM)
Fuel Capacity 4.5 L/1.2 Gal.
Tires FT: 70/100-17 – RR: 90/100-14 Knobby tires
Wheels Steel 1.6 x 17″ / 1.85 x 14″ Rims, DCA Hubs
Frame/Suspension/Brake System
Frame Twin Girders Steel Tube Frame
Front Fork Inverted 45*48-735mm Forks, Non-Adjustable
Rear Shock ￠10*￠11*310mm ,Spring Per-load
Swing-Arm Steel Tube 14inch
Handlebar Steel Crossbar ,L=720mm; Dia=22mm
Front Brake Hydraulic Twin Piston Caliper, 220mm Disc
Rear Brake Hydraulic Single Piston Caliper, 190mm Disc
Exhaust Steel Pipe with catalyst converter(EPA Standard)
Brake & Clutch Lever Foldable
Seat Ribbed TrailMaster Seat
Headlight LED
Packing and Loading
Packing Size(inch) 62.6×14.8×29.9 inch
N.W/LBS 172 LBS
G.W/LBS 203 LBS
